Joint Mate

The Milescraft Joint Mate is a universal dowelling jig for quickly and accurately creating corner, edge and surface joints with ease

• Perform one-handed alignment and skip the hassle of measuring and marking when drilling corner or edge joints with Joint Mate

Features

• Joint Mate allows for quick and accurately dowelled corner, edge or surface joints
• Self-centering jig and adjustable fence allow for precise dowel alignment for maximum joint strength
• Metal bushings ensure accurate alignment when drilling, for perfectly positioned dowels
• Minimal set-up with no exposed or covered mechanical fasteners
• Compatible with 1/2″ to 1-1/2” (12.7mm to 38mm) thick lumber

Selection

• Board Thickness: 12,7-15,87mm | Dowel Pin/Drill Bit: 6mm
• Board Thickness: 15,87-19,05mm | Dowel Pin/Drill Bit: 8mm
• Board Thickness: 19,05-38mm | Dowel Pin/Drill Bit: 10mm
